Fujitsu Ducted Air Conditioner

Fujitsu Ducted Air Conditioner

Fujitsu Ducted Air Conditioner 12.5kWSET-ARTH45KHTA

Product code: 3120081

View Product Specifications

Model Number	SET-ARTH45KHTA
Liquid Connection Size	3/8 "
Gas Connection Size	5/8 "
Indoor Unit Height	425 mm
Indoor Unit Width	1250 mm
Indoor Unit Depth	490 mm
Outdoor Unit Height	998 mm
Outdoor Unit Width	940 mm
Outdoor Unit Depth	320 mm
Indoor Unit Weight	53 kg
Outdoor Unit Weight	67 kg
Cooling Capacity	12.5 kW
Heating Capacity	14 kW
Phase	Single Phase
Nominal Power Supply	230V AC
Maximum Pipe Length	50 m
Maximum Height Difference	30 m

Specification, Manuals & Installation

Product Information Sheet - Fujitsu Ducted 12.5kw Set-Arth45khta

Product Information Sheet - Fujitsu Ducted 12.5kw Set-Arth45khta View
